Comprehensive Guide To Hydraulic Lifting Coil Transfer Trolley

Hydraulic lifting coil transfer trolley can operate freely without an external power supply, is not limited by the number of lifting times, is easy to operate, and can be lifted and lowered freely. Lift buggy can not only lift and lower mold carts at the same time but also lift and lower them separately. Lift buggy is equipped with limit devices to prevent excessive lifting, and the lifting height can stay at any position (limited to below the maximum lifting height).

Lift Buggy 20T Video

Hydraulic lifting device installed on the transfer trolley is testing at our client’s factory. Automated RGV transfer carts offer several advantages over traditional material handling equipment.

Working Process of Hydraulic Lifting Transfer Trolley

The material is hoisted onto lifting buggy by a crane. In order to prevent materials from sliding on lift buggy, a rubber sheet can be laid on the table. The material is transported to the corresponding workstation by electric trolley, and the workpiece is sent to the appropriate position by the hydraulic lifting device.

Custom Lift Buggy

• The height of hydraulic lift buggy can be designed according to the size provided by you, and special devices such as V-frames and roller brackets can be installed on the table.
• Hydraulic lifting electric trolley has its own safety monitoring device, which will automatically stop when encountering pedestrians or obstacles, and is safe and reliable.
• The installation methods of self propelled trolley hydraulic devices are also different. It can not only realize the rise and fall of objects but also realize the rollover function, which is convenient for unloading.
• Lifting buggy can also realize the conversion function of cargo transportation of different shapes, automatic feeding, automatic lifting and lowering, and automatic unloading, and the automation function of the workshop, and is also a necessary tool in the future robot era.

Precautions of Coil Lift Cart

• When loading coils with lift buggy, the coils should be placed in the middle of the V-frame. It is strictly forbidden to use it with an uneven load or overload.
• When placing the coil, it should be stable. It is strictly forbidden to use any loading method that causes a violent impact on lift buggy, such as a fast or violent collision.
• The use of rail lift buggy with the unwinder: When loading the coil, the V-frame must be in the lowest position, that is, the bottom of the V-frame is in direct contact with electric flat car table. After the coil is placed in place and stable, run rail lift transfer cart to the unwinder loading position, then start the oil cylinder, lift the coil into place, slowly lift buggy, push the coil into place, and after the coil is positioned, lower the V-frame to the lowest position, exit rail transfer cart, and use it in this cycle.
• When loading or unloading the coil or when lift buggy for coil is running under load, it is strictly forbidden to stand on both sides of rail cart to prevent accidents.
• When operating coil transfer cart, do not pull the handle control line hard to prevent damage to the aviation plug. Do not touch the end stop of the track during operation.
• Lift buggy should move slowly during operation. It is strictly forbidden to change the direction of travel or apply reverse brakes at a fast speed.
• It is strictly forbidden to use rail transfer trolley to push, hit, drag or pull other transfer carts or objects on the track.
• If lift buggy is inspected, maintained, or deactivated or there is a sudden power outage during operation, transfer cart and transformer power supply must be turned off in time.
• Do a good job of maintenance, lubrication, repair, and cleaning of lift buggy on rail.
